Tire Pressure Monitoring System (TPMS)*
Tire Pressure Monitoring System (TPMS)*
The TPMS indicator
functions as both Low Tire Pressure Light and TPMS Malfunction Indicator. The indicator will illuminate if it detects one or more tires is significantly underinflated, the vehicle has a spare tire installed without TPMS or the outside temperature becomes significantly lower.
- The LCD screen in the Instrument Cluster will display the Low Tire Pressure indicator
showing which tire(s) is underinflated. Inflate tire(s) to specifications using an accurate digital tire pressure gauge to turn off Low Tire Pressure Light . See front driver’s door jamb for PSI specification. - When there is a problem with the TPMS, the TPMS Malfunction Indicatorwill blink for approximately one minute then illuminate – see dealer for service.
Quick Tips:
- Even with TPMS, tire pressure should be checked manually at least once a month. Only adjust tire pressure on “cold tires” that have been sitting for 3 hours or more, and tires that are not hot in temperature from direct sunlight or heat
- For proper maintenance and optimal fuel economy, maintain recommended tire inflation pressures and stay within the load limits and weight distribution recommended for your vehicle
- A significant drop in temperature may cause tire inflation pressures to drop, which may activate the TPMS light. Manually confirm tire pressures after significant changes in temperature or altitude
Reminders:
- Check the recommended tire pressure label located on the left side of driver’s door jamb, visible when the door is open
- Consult your dealer for service if Low Tire Pressure Light remains illuminated after inflating your tire(s)
*See LEGAL page for legal information.
-
Personal electronic devices (such as laptops, wireless chargers, remote start systems, etc.) may interfere with TPMS system, which may cause the Malfunction Warning Indicator (Check Engine Light) to illuminate.
-
Images are for illustrative purposes only and may not reflect actual feature or operation. See section 8 in the Owner’s Manual for more information.
